Product Name: PFA / FEP LINED DIAPHRAGM VALVE

Product Code : DV

Product Display Name : LINED DIAPHRAGM VALVE

DESCRIPTION:

SIZE RANGE: 1” – 12”

MATERIAL OF CONSTRUCTION:

BODY: Ductile Iron A395 or SS A351 CF8, Lining PFA – D3307 Type II or FEP – D2116 Type III

BONNET, BUSH, HAND WHEEL and COMPRESSER: Cast Iron

SPINDLE, LOCK SCREW, STUDS and COMPRESSION PIN: SS304

COLLAR: Cast Carbon Steel

DIAPHRAGM: PTFE WITH Neoprene backing

DIAPHRAGM STUD: Brass

SURFACE: External surface are painted with Red oxide primer.

Dimensional details are as per below table
